Minus 25C 10KW 20KW High COP DC Inverter Split Air to Water Heat Pump.
1.ASHP Heating Capacity: DC Inverter Split 10KW 20KW.
2.Best Selling Market: Central Europe North & East Europe, North Europe, North America.
3.Ambient Temp of Using: Minus 25C, highest 55-60C hot Water Output.
4.Certification: ISO9001, CE, erP Energy Label, ROHS, EMC.
5.Japan *Mitsubishi" Twin Rotor Compressor for DC Inverter Split Air Source Heat Pump.
HEAT PUMP TYPE | DC Inverter Type Split Heat Pump Air to Water Heating Cooling |
| MANUFACTURER | NULITE NEW ENERGY Group |
FACTORY SCALE | with in total 3 factory in China, 400,000 sq meters. 500,000 units producing ability, 100,000 units sold in 2016 |
| HEAT PUMP FUNCTION | Radiator, FCU, Floor Heating Cooling & Hot Water |
| MOQ | 10-20 Units(1-2 Sample available with stocks) |
| EFFICIENCY | COP 3.5-4.9 at Ambient 7C-25C |
SUITABLE MARKET | Minus 25C stable Working Central, North & East Market, North America |
SUITABLE HEATING SPACE | TYPE OF HEAT PUMP USING AREA MODEL NAME DC Inverter Split Heat Pump 10KW (60-100m2) BKDX30-95 DC Inverter Split Heat Pump 20KW (150-200m2) BKDX50-200 |
| Item | BKDX30-95I/150S | BKDX50-200I/150S | BKDX60-220I/150S | |||||
| Rated heating capicity | KW | 10 | 20 | 22 | ||||
| Rated cooling capicity | KW | 2.7-6.6KW | 4.5-11KW | 5.2-13.5KW | ||||
| Max input power | KW | 1-3KW | 2-5.5KW | 2.5-6.6KW | ||||
| Rated current | A | 12 | 20 | 8 | ||||
| Indoor unit Power supply | V/Hz | 220V 50Hz/60Hz | 220V 50Hz/60Hz | 220V 50Hz/60Hz | ||||
| Outdoor unit Power supply | V/Hz | 220V 50Hz/60Hz | 220V 50Hz/60Hz | 220V 50Hz/60Hz | ||||
| Rated output water temperature | °C | 45 | ||||||
| Max output water temperature | °C | 60 | ||||||
| Water flow | m³/h | 2.2 | 3.5 | 3.9 | ||||
| Refrigeration | R410A | |||||||
| Rated of waterproof | IPX4 | IPX4 | IPX4 | |||||
| Prevent leakage protection | I class | I class | I class | |||||
| Control mode | Microcomputer central processor (linear control) | |||||||
| Compressor | Form | Scroll type | Scroll type | Scroll type | ||||
| Quantity | 1 | 1 | 1 | |||||
| Brand | Mitsubishi Twin Rotor DC Inverter | |||||||
| Fan | Form | internal rotor motor,plastic leaves | ||||||
| Fan power | W | 90 | 90*2 | 90*2 | ||||
| Outdoor unit | Net size | mm | 910*445*977 | 979×418×1200 | 979×418×1200 | |||
| Weight | Kg | 92 | 112 | 120 | ||||
| Nosie level | dB(A) | ≤54 | ≤60 | ≤60 | ||||
| Indoor unit | Auxilary heater | KW | 3 | 3 | 3 | |||
| heat exchanger | stainless steel plate heat exchanger | |||||||
| Net size | mm | 410*265*606 | 500*276*606 | 500*276*606 | ||||
| Ambient temperature | °C | (-25℃ -- 46℃） | (-25℃ -- 46℃） | (-25℃ -- 46℃） | ||||
| Inlet pipe diameter | DN25 | DN25 | DN25 | |||||
| Outlet pipe diameter | DN25 | DN25 | DN25 | |||||
| Test Conditions Heating : Ambient temp.7°C/6°C,Water temp.40°C/45°C Cooling: DB / WB: 35°C/24°C Water Input:12°C ,Water Output:7°C | ||||||||
01.COP up to 4.4 30C/35C working condition
The application of EVI technology together with high efficiency heat exchanger can improve the heat exchanging rate and make the COP up to 4.4
02.Ambient Temp -25C Show perfect performance
NE EVI Series Heat Pumps get perfect performance at ambient temperature -25C to ensure stable running all year round.
03.Highest outlet water temp. 60C
Due to outlet water up to 60C, the unit can replace the traditional boilers which are applied to the house heating and domestic hot water
Heat Pump Packing Details : stable plywood box package, 1.25CBM for 4HP 5HP EVI split heat pump
Heat Pump Delivery Details : 1-25 working days after receiving payment by T/T, or alibaba trade assurance payment
Heat Pump Dealing Details: EXW factory, FOB Guangzhou/Shenzhen Port, CIF to destination Port, DDP Service provided
NULITE NEW ENERGY Heat Pump in ISH 2017
The Germany customers is very satisfied with NULITE NEW ENERGY ASHP factory scale, heat pump quality, and the technology innnovation of EVI DC Inverter high efficiency & Minus 35C stable working solutions
NULITE NEW ENERGY HEAT PUMP in Europe
NULITE NEW ENERGY Heat Pump of EVI Split & DC Inverter Split Heat Pump is well sold in Europe and North America market, including US, Canada, Germany, Poland, Ukraine, Russia, Finland, Czech, Slovenia, etc.
NULITE NEW ENERGY EVI Heat Pump at South Pole with Extreme Cold Climate
NULITE NEW ENERGY Heat Pump is the official heat pump supplier for the 18th Asian Games and for China North & South Pole Expedition Team.
