5.39KW household all in one heat pump for DHW model FDV1.5/Y220

5.39KW household all in one heat pump for DHW model FDV1.5/Y220

Model
FDV1.5/Y220
MOQ
10-20 Units(1-2 Sample available with stocks)
Place of Origin
china
Delivery Time
7-15 working days
Payment Terms
L/C , T/T, WEST UNION
Certification
ISO9001, CE, erP Energy Label, ROHS, EMC
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Specification
ItemNERS-FDV1.5/Y160FDV1.5/Y220
Rated heating capicityW53905390
Input powerW12751275
Voltage V/Hz220V-50Hz
Rated output water temperature °C55°C
Max output water temperature°C70°C
Water tank capacityL160L220L
Refrigeration
R134A
Control mode
Microcomputer central processor (touch control)



Compressor

Form
Rotation type
Quantity
11
Brand
Mitsubishi



UNIT

Net sizemm583*339*1782741*444*1845
WeightKg91115
Nosie leveldB(A) <50


Fan

Form
centrifugal
Fan power W50

Water tank
built-in

coil


aluminum
Ambient temperature
(-10℃ --  46℃)
Inlet pipe diameterDN15
Outlet pipe diameterDN15
Payment terms:T/T, 30% in advance, 70% balance before shipment.
Delivery time:  30 working days after deposit, right away after balance.
Other refrigerants,other prices
Package: carton plus woods
Parameter testing condition:
DB/WB:20℃/15℃, Water In/Out:15℃/55℃


All in one heat pump:

  •

    1.70°C output water temperature and super COP 4.23.

  •

    2.Using R134A green refrigeration.

  •

    3.Energy saving 75%, saving more running cost.

  •

    4.Square design and monoblock type,easy installation .

  •

    5.Strong insulation effect, 24 hours water temperature only drop<3 °C.

  •

    6.Dual tank technology, higher water output quantity.

Product Advantage


 DUAL WATER TANK SERIES

Small size with more hot water valume

NULITE-539kw Household All In One Heat Pump, Monobloc Air Source Heat Pump

1.Luxury LED touch controller
Luxury LCD screen, touch control, flexible water temp. Adjustment, multiple running modes are available, enjoy comfortable hot water.
2.Max water temperature reaches 70℃
Cold water continuously heat transfer with multiple heat exchangers,max Output water temp. Can reach 70℃, hot water output quantity is much higher than ordinary heat pump unit.
3.Dual water tank heat transfer technology
Hot and cold water storage separated, mixed water is small, heat more thoroughly, making the heat pump water output quantity each 125%.

Heat Pump Details



ALL-IN-ONE MONOBLOCK AIR TO WATER HEAT PUMP.

  •

    1.ASHP Heating Capacity:  All-in-one 3.79KW 5.39KW.

  •

    2.Best Selling Market:  Central, North & East Europe, North Europe, Asia.

  •

    3.Ambient Temp of Using:  Minus 15C, highest 70C hot Water Output.

  •

    4.Certification: ISO9001, CE, erP Energy Label, ROHS.

  •

    5.Use *Mitsubishi* dual-rotor Compressor for all-in-one Air Source Heat Pump.


HEAT PUMP TYPE

Monoblock All-in-one Heat Pump Air to Water Heat Pump

ALL-IN-ONE 3.79KW(160L)-5.39KW(160L/220L)

DHW+FREE COOLING

MANUFACTURERGuangdong NULITE new energy Group

FACTORY SCALE

with in total 3 factory in China,

400,000 sq meters. 500,000 units producing ability, 100,000 units sold in 2016

HEAT PUMP FUNCTIONRadiator, FCU, Floor Heating Cooling & Hot Water
MOQ5-10 Units(1-2 Sample available with stocks)
EFFICIENCYCOP 3.5-5 at Ambient 7C-25C

SUITABLE MARKET

Minus 15C stable Working

Asia,Central, North & East Europe



SUITABLE HEATING SPACE

         TYPE OF HEAT PUMP                MODEL NAME          USING AREA

All-in one Heat Pump 3.79KW(160I)      FDV1/Y160             (3-4 persons)

All-in one Heat Pump 3.79KW(160I)      FDV1.5/160            (3-4 persons)
All-in one Heat Pump 3.79KW(160I)      FDV1.5/220            (4-5 persons)
