| GB series commercial heat pump | |||||||||||
| Model | NERS- | G/3B | G/5B | G/6B | G/8B | G/10B | G/12B | G/20B | G/24B | G/40B | |
| Rated heating capicity | KW | 11.4KW | 19.7KW | 23.57KW | 30kw | 38.5KW | 44.7KW | 72KW | 90.3KW | 140KW | |
| Input power | KW | 2.57KW | 4.45KW | 5.3KW | 7.5KW | 8.73KW | 10.11KW | 18KW | 20.3KW | 35.4KW | |
| Voltage | V/Hz | 380V-50Hz | 380V-50Hz | 380V/50Hz | 380V-50Hz | 380V-50Hz | 380V-50Hz | 380V-50Hz | 380V-50Hz | ||
| Rated output water temperature | °C | ||||||||||
| Rated output water quantity (L) | L | 240 | 420 | 507 | 645 | 830 | 960 | 1504 | 1940 | 3010 | |
| Refrigeration | R407C | ||||||||||
| Control mode | intelligent control ，touch control | ||||||||||
| Form | scroll | |||||||||
| Quantity | 1 | 1 | 1 | 2 | 2 | 2 | 2 | 2 | 4 | ||
| Brand | internal rotor motor | ||||||||||
| Net size | mm | 719*719*944 | 829*829*1122 | 829*829*1122 | 1480*853*1348 | 1480*853*1348 | 1480*853*1348 | 2120*980*1920 | 2120*980*1920 | 2180*1797*1806 |
| Weight | Kg | 94 | 127 | 138 | 325 | 335 | 340 | 691 | 750 | 1450 | |
| Nosie level | dB(A) | 54 | 60 | 60 | 64.5 | 64.5 | 64.5 | 70 | 74 | 76 | |
| Fan | Form | ||||||||||
| ambient temperature | °C | -10~43 | |||||||||
| Inlet pipe diameter | DN20 | DN25 | DN25 | DN40 | DN40 | DN40 | DN80 | DN80 | DN80 | ||
| Outlet pipe diameter | DN20 | DN25 | DN25 | DN40 | DN40 | DN40 | DN80 | DN80 | DN80 | ||
Test condition: | |||||||||||
Air to water heater heat pump manufacturer
1.Compressor: Copelan*ZW series compressor with R417a/R407C/R410 refrigerant.
2.Internal rotor motor, magnesium aluminum alloy leaves.
3.Reverse preventing frosting function of evaporator, hydrophilic fin.
4.Colored plate, with fashion appearance design.
5.Super performance in high COP, can work under the ambient temperature range from -10 to 43 degree.
6.Intelligent Microcomputer controller.
7.Low noise.
1.Water cycle heat pump
Absorbed a lot of energy in the air,the COP＞4.0 and 75% energy saving
2.Storage water tank
Used the big large capacity insulated water tank for 24H required hot water
3.Domestic hot water
Central thermostat hot water,to meet the multi-point supply at the same time
Heat water for pressure free water tank
 |  |
 |  |
Water park hot water project |
Factory hot water project |
Swimming pool projects |
 |  |  |
| HEAT PUMP PACKAGE STEP 1 | HEAT PUMP PACKAGE STEP 2 | HEAT PUMP PACKAGE STEP 3 |
 |  | |
| HEAT PUMP PACKAGE STEP 4 | HEAT PUMP PACKAGE STEP 5 | HEAT PUMP PACKAGE STEP 6 |
